Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 105
Connect the Kinetix 6200 and Kinetix 6500 Drive System Chapter 5
Power Wiring Guidelines
Use these guidelines as a reference when wiring the power connectors on your
IAM and AM power modules.
For IPIM module power wiring guidelines, refer to the Kinetix 6000M
Integrated Drive-Motor System User Manual, publication 2094-UM003
.
Follow these steps when wiring the connectors on your IAM and AM power
modules.
1. Prepare the wires for attachment to each connector plug by removing
insulation equal to the recommended strip length.
2. Route the cable/wires to your IAM and AM power modules.
3. Insert wires into connector plugs.
Refer to connector pinout tables in Chapter
4 or the interconnect
diagrams in Appendix
A.
4. Tighten the connector screws.
5. Gently pull on each wire to make sure it does not come out of its
terminal; reinsert and tighten any loose wires.
6. Insert the connector plug into the module connector.
IMPORTANT For connector locations of the Kinetix 6200 and Kinetix 6500 drive modules,
refer to 2094 Power Module and Control Module Features on page 62
.
When tightening screws to secure the wires, refer to the tables beginning on
page 103
for torque values.
When removing insulation from wires, refer to the tables beginning on
page 103
for strip lengths.
IMPORTANT To improve system performance, run wires and cables in the wireways as
established in Establishing Noise Zones on page 39
.
IMPORTANT Use caution not to nick, cut, or otherwise damage strands as you
remove the insulation.
