122 Rockwell Automation Publication 2094-UM002G-EN-P - August 2016

Chapter 5 Connect the Kinetix 6200 and Kinetix 6500 Drive System

Flying-lead Feedback Cable Pinouts

Refer to the following tables for the motor-to-drive feedback cable pinout used

in your application.

Table 80 - 2090-XXxFMP-Sxx Feedback Cable

Bayonet

Connector

High-resolution Feedback

Drive MF

Connector Pin

Rotary Motor

Connector Pin

MPL-B3xxx…MPL-B9xxx-M/Sx2xAA,

1326AB-Bxxx-M2L/S2L

ASin+ 1

BSin- 2

CCos+ 3

DCos- 4

EData+ 5

FData- 10

KReserved 14

LReserved 6

NEPWR_9V 7

PECOM 6

RTS+ 11

STS- –

TReserved 12

UReserved 13

VReserved 8
