Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 132
D-Link UWS User Manual
• If you change any settings or add an excluded address range, click Submit to apply the changes to the
system. Each time you enter a value in the From or To fields, click Submit to add the address or address
range to the excluded address list.
• To Delete an address or address range from the excluded address list, select one or more check box
beneath the Delete Excluded Addresses field and click Submit.
Add Excluded Addresses Use the From and To fields to specify the IP addresses that the server should
not assign to the client. If you want to exclude a range of addresses, set the
range boundaries.
Note: It is strongly recommended not to add thousands of addresses in the
range. The larger the range, more time will be taken by the DHCP server to
assign an IP address.
From To exclude an address range, specify the low address in the range.To specify a
single address to exclude, enter the address in the From field and leave the To
field at the default value of 0.0.0.0. For example, in Figure 57 on page 133, the
user is adding the address 192.168.17.100 to the excluded addresses list.
To To exclude an address range, specify the high address in the range. To exclude
a single address, do not enter a value in this field.
Delete Excluded Addresses After you add excluded addresses, they appear below this field title, as
Figure 57 on page 133 shows. Each address or address range has a check box
next to it.
Table 48: DHCP Server Global Configuration Fields (Cont.)
Field Description
