Configuring SNTP Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 99
D-Link UWS User Manual
• If you change any of the settings on the page, click Submit to apply the changes to system.
SNTP Server Configuration
Use the SNTP Server Configuration page to view and modify information for adding and modifying Simple
Network Time Protocol SNTP servers.
To display the SNTP Server Configuration page, click LAN > Administration > SNTP > SNTP Server
Configuration in the navigation tree.
Figure 31: SNTP Server Configuration
Unicast Poll Timeout Specifies the number of seconds to wait for an SNTP response when
configured in unicast mode. Allowed range is (1 to 30). Default value is 5.
Unicast Poll Retry Specifies the number of times to retry a request to an SNTP server after the
first time-out before attempting to use the next configured server when
configured in unicast mode. Allowed range is (0 to 10). Default value is 1.
Table 26: SNTP Server Configuration Fields
Field Description
Server Select the IP address of a user-defined SNTP server to view or modify
information about an SNTP server, or select Create to configure a new SNTP
server. You can define up to three SNTP servers.
Address / Hostname Enter the IP address or the hostname of the SNTP server.
Address Type Select IPv4 if you entered an IPv4 address or DNS if you entered a hostname.
Port Enter a port number from 1 to 65535. The default is 123.
Priority Specifies the priority of this server entry in determining the sequence of
servers to which SNTP requests are sent. Values are 1 to 3, and the default is
1. Servers with lowest numbers have priority
Version Enter the protocol version number. Values are 1 to 4, and the default is 4.
Table 25: SNTP Global Configuration Fields (Cont.)
Field Description
