D-Link DWL-2600AP User Manual

Configuring sFlow
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 154
D-Link UWS User Manual
• Use the Refresh button to refresh the page with the most current data from the switch.
sFlow Receiver Configuration
Use the sFlow Receiver Configuration page to configure the sFlow Receiver.
To access the sFlow Receiver Configuration page, click LAN > Administration > sFlow > Receiver Configuration
in the navigation tree.
Figure 75: sFlow Receiver Configuration
Table 66: sFlow Agent Summary
Field Description
Version Uniquely identifies the version and implementation of this MIB. The version string must have
the following structure: MIB Version;Organization;Software Revision where:
• MIB Version: ‘1.3’, the version of this MIB.
• Organization: D-Link Corporation
• Revision: 1.0
Agent Address The IP address associated with this agent.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
