D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 458
D-Link UWS User Manual
AP Image Capability
The switch is able to update software on the access points that it manages. To update the AP with the correct
software, the UWS can store up to three AP software images to support different AP hardware types. This page
displays the image ID-to-hardware type mapping.
Figure 309: Image Table
Table 264: AP Image Capability
Field Description
Image Type ID Shows the ID number assigned to the image.
Image Type Description Provides a basic description of the image.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
