D-Link DWL-2600AP User Manual

Configuring SNTP Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 98
D-Link UWS User Manual
MD5 (Message Digest 5) Authentication safeguards device synchronization paths to SNTP servers. MD5 is an
algorithm that produces a 128-bit hash. MD5 is a variation of MD4, and increases MD4 security. MD5 verifies
the integrity of the communication, authenticates the origin of the communication.
SNTP Settings
Use the SNTP Global Configuration page to view and adjust SNTP parameters.
To display the SNTP Global Configuration page, click LAN > Administration > SNTP SNTP Settings in the
navigation menu.
Figure 30: SNTP Global Configuration
Table 25: SNTP Global Configuration Fields
Field Description
Client Mode Use drop-down list specify the SNTP client mode, which is one of the following
modes:
• Disable: SNTP is not operational. No SNTP requests are sent from the
client nor are any received SNTP messages processed.
• Unicast: SNTP operates in a point to point fashion. A unicast client sends a
request to a designated server at its unicast address and expects a reply
from which it can determine the time and, optionally the round-trip delay
and local clock offset relative to the server.
• Broadcast: SNTP operates in the same manner as multicast mode but uses
a local broadcast address instead of a multicast address. The broadcast
address has a single subnet scope while a multicast address has Internet
wide scope.
Port Specifies the local UDP port to listen for responses/broadcasts. Allowed range
is (1 to 65535). Default value is 123.
Unicast Poll Interval Specifies the number of seconds between unicast poll requests expressed as
a power of two when configured in unicast mode. Allowed range is (6 to 10).
Default value is 6.
Broadcast Poll Interval Specifies the number of seconds between broadcast poll requests expressed
as a power of two when configured in broadcast mode. Broadcasts received
prior to the expiry of this interval are discarded. Allowed range is (6 to 10).
Default value is 6.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
