D-Link DWL-2600AP User Manual

Configuring Time Ranges
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 144
D-Link UWS User Manual
Click Submit to create the time range entry. Configuration changes take effect immediately. These changes will
not be retained across a power cycle unless a save is performed.
Periodic Time Range Entry
Applicable Days Specify the day(s) when the time entry occurs:
• Daily — Has the same start and end time every day
• Weekdays — Has the same start and end time Monday through Friday
• Weekdays — Has the same start and end time on Saturday and Sunday
• Days of the Week — Select the day of the week when the entry starts and
stops. You do not need to use the same day of the week for the start and
end time.
Start Day (Periodic Days of Week only) Select the day the time range entry starts. To
select multiple days, hold the CTRL key and click the days.
Start Time Specify the time when the entry begins. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
End Day (Periodic Days of Week only) Select the day the time range entry ends.
End Time Specify the time when the entry ends. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
Absolute Time Range Entry
Absolute Start Date and Time Select the check box to configure the date and time when the time range entry
begins.
Start Month Select the month when the time entry begins.
Start Date Select the day of the month when the time entry begins.
Start Year Select the year when the time entry begins.
Start Time Specify the time when the entry begins. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
Absolute End Date and Time Select the check box to configure the date and time when the time range entry
ends.
End Month Select the month when the time entry ends.
End Date Select the day of the month when the time entry ends.
End Year Select the year when the time entry ends.
End Time Specify the time when the entry ends. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
Table 57: Time Range Entry Configuration
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
