D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 519
D-Link UWS User Manual
Authentication Status Indicates whether this client is authenticated.
Note: The Client Status can be Rogue, but the authentication status can still be
Authenticated.
Threat Detection Indicates whether one of the threat detection tests has been triggered for this client.
If the test is disabled, the client will not be marked as a rogue, but you can still
investigate why the threat was triggered.
Threat Mitigation
Status
Indicates whether threat mitigation has been done for this client.
Time Since Entry Last
Updated
Shows the amount of time that has passed since any event has been received for this
client that updated the detected client database entry.
Time Since Entry Create Shows the amount of time that has passed since this entry was first added to the
detected clients database.
Client Name Shows the name of the client, if available, from the Known Client Database. If the
client is not in the database then the field is blank.
RSSI If the client is authenticated with the managed AP, this field displays the last RSSI
value reported by the AP with which the client is authenticated. The RSSI is a
percentage from 1–100%. A value of 0 means the AP is not detected.
Signal Last signal strength reported by the managed AP with which the client is
authenticated. The possible range is –128 to 128 dBm.
Noise Last channel noise reported by the managed AP with which the client is
authenticated. The possible range is –128 to 128 dBm.
Probe Req Recorded Number of probe requests recorded so far during the probe collection interval.
Probe Collection
Interval
Shows the amount of time spent in each probe collection period. The probe
collection helps the switch decide whether the client is a threat.
Highest Probes
Detected
Shows the largest number of probes that the switch detected during a probe
collection interval.
Channel Identifies the channel that the client is using.
OUI Description The organization name associated with the detected client’s Organizationally Unique
Identifier (OUI).
Auth Msgs Recorded Shows the number of IEEE 802.11 Authentication messages recorded so far during
the authentication collection interval.
Auth Collection Interval Shows the amount of time spent in each authentication collection period. The
authentication collection helps the switch decide whether the client is a threat.
Highest Auth Msgs Shows the largest number of authentication messages that the switch detected
during an authentication collection interval.
De-Auth Msgs
Recorded
Shows the number of IEEE 802.11 De-Authentication messages recorded so far
during the deauthentication collection interval.
De-Auth Collection
Interval
Shows the amount of time spent in each de-authentication collection period. The
deauthentication collection helps the switch decide whether the client is a threat.
Highest De-Auth Msgs Shows the largest number of de-authentication messages that the switch detected
during a deauthentication collection interval.
Authentication Failures Shows the number of 802.1X Authentication failures detected for this client.
Probes Detected Shows the number of probes detected in the last RF Scan.
Table 309: Detailed Detected Client Status (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
