GE RAFT VOLUSON™ P8 / VOLUSON™ P6
DIRECTION 5723243, R
EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL
3-48 Section 3-7 - Printer Installation
3-7-7 Adjustment of Printer Settings
1.) After system restart, press the UTILITIES key on the control console.
2.) In the “Utilities” menu select SETUP
button to invoke the setup desktop on the screen.
3.) On the right side of the screen select CONNECTIVITY
and then click on the PERIPHERALS tab.
4.) Select the desired printer from the Printer Settings pull-down menu and click the EDIT
button..
To adjust the UP-D898 printer see: Section 3-7-7-1 "UP-D897 / UP-D898MD - Printer Settings" .
To adjust the UP-D25MD Printer see: Section 3-7-7-2 "UP-D25MD - Printer Settings" .
Figure 3-50 Select the desired printer
!! WARNING:
After each printer installation, the leakage currents have to be measured
acc. IEC 60601-1 resp. UL 60601-1.
