GE DRAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-29

3.) Remove the TOP CABINET COVER BT16. Refer to the figure below.

8-11-4 Installation Procedure

Install the new parts in the reverse order of removal procedure.

Figure 8-27 Removing the TOP CABINET COVER BT16

TOP CABINET COVER BT16
