GE DRAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-171

8-52-5 VERTICAL TV PROBE HOLDER Installation

1.) Install VERTICAL TV PROBE HOLDER BASE on the right side bottom of OPIO with 2 screws.

2.) Place the TV PROBE HOLDER RUBBER on the PROBE HOLDER BASE.

Figure 8-244 Assembling TV PROBE HOLDER BASE with 2 screws (2159634, BH M4x10)

Figure 8-245 Inserting TV PROBE HOLDER RUBBER to PROBE HOLDER BASE

TV PROBE

HOLDER BASE

HOLDER

RUBBER
