GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

3-18 Section 3-5 - Connection of Auxiliary Devices

3-5-4 Connecting the DeskJet Color Printer

3-5-4-1 Connection via Bluetooth Adapter

The DeskJet Color Printer can be connected to an external, non-isolated power source. The bluetooth

adapter should be directly connected to the indicated USB 3 on rear panel

Figure 3-8 HP Officejet H470 DeskJet Printer connection (via Bluetooth Adapter)

Power Cable

connected to the

rear side

Bluetooth

Printer Adapter

of the printer

USB Bluetooth Adapter

connected to USB port
