GE DRAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-93

Section 8-28

Replacement of the NEST

8-28-1 Manpower

One person, 10 minutes

8-28-2 Tools

Philips screwdriver, Allen Wrench

8-28-3 Preparations

1.) Power Off/Shutdown the system as described in 4-3-2 on page 4-4.

8-28-4 Removal Procedure

1.) Remove the FRONT CABINET BEZEL ASSY BT16. Refer to the figure below.

Figure 8-139 Removing the FRONT CABINET BEZEL ASSY BT16

FRONT CABINET BEZEL

ASSY BT16
