GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

3-56 Section 3-8 - Cellular Modem Installation

3-8-5 Installation procedure

1.) To refer to below picture, Unplug power cable for cellular modem and cut cable tie.

2.) Slide up the upper cover of the Cellular Modem(Pos.1)to get access to the SIM card holder.

Figure 3-59 Unpluging power cable

Figure 3-60 Sliding up the upper cover
