3-54 Section 3-8 - Cellular Modem Installation

Section 3-8

Cellular Modem Installation

3-8-1 Overview

This section describes the installation procedure of Cellular Modem Kit.

3-8-2 Tools Required

Standard Field Service Tool Kit.

3-8-3 Parts Required

Table 3-1 H48691WL Cellular Modem option kit

No Part No. Part Name Q’ty

1 KTZ304025 Cellular Modem 1

Figure 3-56 Cellular Modem option kit
