5-20 Section 5-2 - General Information
5-2-5 Description of Hardware Options
5-2-5-1 CW - Continuous Wave Doppler
CW Doppler mode provides real time spectral analysis of CW Doppler signals. This information
describes the Doppler shifted signal from the moving reflectors in the CW Doppler beam. CW Doppler
can be referenced through a small pencil probe or phased array scan head, but it can also be used in
conjunction with a 2D image which has an M-line superimposed on the 2D image indicating the position
of the Doppler sample volume. For through-the-beamformer CW, this beam is steerable by the operator,
and is done by adjusting the location of the M-line. The CW Doppler beam, or M-mode line, can be
steered allowing interrogation along an operator-selected line within the image.
NOTE: This feature is available only on Voluson P8
TM
systems.
5-2-5-2 ECG Module
For details see: Section 5-10-3 "ECG Module" on page 5-39
5-2-5-3 Wireless Network Adapter (WLAN - Wireless Local Area Network)
For details see: Section 5-10-4 "Wireless Network Adapter" on page 5-39
5-2-5-4 DPS2 Battery Assy
For details see: Section 5-10-5 "DPS2 Battery Assy" on page 5-39
Table 5-3 Hardware Options
HW-Options Description
1
CW-Doppler
5-2-5-1 CW - Continuous Wave Doppler
2
ECG Module
5-2-5-2 ECG Module
3
WLAN Network Adapter
5-2-5-3 Wireless Network Adapter (WLAN - Wireless Local Area Network)
4
DPS with Battery Assy
5-2-5-4 DPS2 Battery Assy
