GE DRAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-147

Section 8-47

Replacement of the CSI

8-47-1 Manpower

One person, 30 minutes

8-47-2 Tools

Philips screwdriver

8-47-3 Preparations

1.) Power Off/Shutdown the system as described in 4-3-2 on page 4-4.

2.) Pull out the NEST as described in Section 8-28 "Replacement of the NEST" on page 8-93

8-47-4 Removal Procedure

1.) Unscrew 4 screws to remove the LED Indicator bracket.

Figure 8-209 Opening the rear bracket
