GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

5-40 Section 5-11 - Power Distribution

Section 5-11

Power Distribution

5-11-1 ACFE - Primary Power Module

Figure 5-18 Primary Power Module

Curcuit breaker

Equipotential Connection

Main Voltage Indicator

(Shows input voltage level)

Pull-out Protection

Main power cable

Important Precautions3
