GE DRAFT VOLUSON™ P8 / VOLUSON™ P6
DIRECTION 5723243, R
EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-23
Section 7-6
How to use the Auto Tester program
1.) Press the UTILITIES key on the control panel.
2.) In the “Utilities” menu select SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) If not already done, connect the USB “standard GE” service dongle to the USB connector(s) on the
rear of the system. As soon as the dongle is detected the login window pops up.
4.) Enter the “Standard GE Revolving” password (changes every six months) and then click ENABLE.
5.) On the left side of the screen select ADMINISTRATION and then click the SERVICE tab.
6.) Click the SERVICE TOOLS
button on the Service window to get access to the “Service Tools” page.
7.) Activate the “Auto Tester” program by clicking START
. The following message box appears.
8.) Click OK
.
9.) Press the ALT GR
key on the alphanumeric keyboard.
10.)Activate the “Auto Tester” program by clicking the “Record” icon on the displayed screen.
Figure 7-25 Message Box
Figure 7-26 Autotester record
