9-6 Section 9-5 - LCD Monitor

Section 9-5

LCD Monitor

Figure 9-2 LCD Monitor

Table 9-4 LCD Monitor

Item Part Name Part Number Description Qty FRU BT13 BT14 BT15 BT16

201

TE17INCH LCDMON

5669733

17" LED Monitor

11 N N N Y

202

17INCH MONITOR

ARM BT16

5722185

17” MONITOR ARM

BT16

11 N N N Y

203

17INCH MONITOR

ARM COVER BT16

5720705

17” MONITOR ARM

COVER BT16

11 N N N Y

204

Tetris HDMI Cable

5717001

Tetris HDMI Cable

1 1 N N N Y

205

Tetris Monitor Power

Cable

5717002

Tetris Monitor Power

Cable

1 1 N N N Y

206

Tetris Monitor USB

Cable

5717003

Tetris Monitor USB

Cable

1 1 N N N Y

207

TE17INCH COVERS

5728055

TE17INCH COVERS

11 N N N Y

201

202

207

203
