GE DRAFT VOLUSON™ P8 / VOLUSON™ P6
DIRECTION 5723243, R
EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL
Chapter 4 - Functional Checks 4-23
4-5-6-2 Load Image Archive
1.) Press the F2
key on the control panel.
2.) In the “Utilities” menu select SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select BACKUP
and then click the IMAGE ARCHIVE tab.
4.) Click the LOAD
button (see: Figure 4-23 on page 4-21).
5.) Choose the Destination.
6.) Click on the backup to be restored (additional information is displayed in the table).
7.) Select the NEXT
button. The following window will be displayed.
8.) Select (check mark) the image archive data to be restored to the Voluson™ P8 / Voluson™ P6
system.
9.) Click the NEXT
button and then select YES to start, or NO to cancel the restore procedure.
Figure 4-26 Image Archive Load - choose destination
Figure 4-27 select image archive data to be restored
