GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

4-6 Section 4-3 - General Procedure

4-3-3 System Features

4-3-3-1 Control Panel

Figure 4-5 Control Panel Tour

1. Loudspeaker position 7. Menu window flipswitch controls

2. Menu window digipot controls 8. Mode keys(digipot controls)

3. TGC Slider controls 9. Toggle switch controls

4. Trackball 10. Hard keys

5. Alphanumeric Keyboard 11. Trackbal buttons

6. Probeholders
