GE DRAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-175

Section 8-56

Replacement of CWD piggy

8-56-1 Manpower

One person, 30 minutes.

8-56-2 Tools

Philips screwdriver, Hirose ejector

8-56-3 Preparations

Power Off/Shutdown the system as described in 4-3-2 on page 4-4.

8-56-4 Removal Procedure

1.) Unscrew 2 screws and remove POWER CORD FIX BRKT and power cord.

Figure 8-247 Power Bracket

POWER CORD FIX BRACKET

power cord
