GE RAFT VOLUSON™ P8 / VOLUSON™ P6
DIRECTION 5723243, R
EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL
5-28 Section 5-4 - BackEnd Processor
Table 5-5 Voluson™ P8 / Voluson™ P6 - DRFM components
5-4-1 Hard Disk Drive
The Hard Disk is the main storage device of the Voluson™ P8 / Voluson™ P6.
The Voluson™ P8 / Voluson™ P6 500 Gbyte Hard disk, which is controlled by the CPU via signals from
SATA, is divided into 4 partitions.
For further details see: Section 5-2-6 "Data Location" on page 5-21.
5-4-2 SOM (System On Module)
5-4-2-1 Congatec
SOM Module for VS6/S8/S10
- On Board HDMI, LAN, USB 2.0, Sound
- CPU: Intel
®
Core
TM
i5-3610ME Processor, 2.7GHz
SOM Module for VP6/P8
- On Board HDMI, LAN, USB 2.0, Sound
- CPU: Intel
®
Core
TM
i3-3120ME Processor, 2.4GHz
Major Tasks:
- System Control
- 2D- / 3D- / 4D- Image processing and Rendering
Sub-section Description Page Number
5-4-1
Hard Disk Drive
5-28
5-4-2
SOM (System On Module)
5-28
