GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

9-22 Section 9-12 - Probes

9-12-4 2D-Probes - Phased Array Transducers

Figure 9-11 2D Phased Array Probe

* The part is only applied for VP8

Table 9-15 2D-Probes - Phased Array Transducers

Item Part Name Part Number Description Qty CRU FRU

807 3Sc-RS*

47237516

(H45041DL)

Broadband phased array

transducer, 1.0 - 4.0 MHz, 64

Elements Applications:

Abdominal, Cardiology,

Obstetrics, Pediatrics, Cephalic

111

807
