BRAKES
B2050, B2350, B2650, B3150, WSM
5-S2
2. SERVICING SPECIFICATIONS
9Y1210982BRS0002US0
Item Factory Specification Allowable Limit
Brake Pedal Free Travel
(ROPS)
30 to 40 mm
1.2 to 1.5 in.
on the pedal
–
Free Travel
(CABIN)
20 to 30 mm
0.79 to 1.1 in.
on the pedal
–
Parking Brake Free Travel 2 notches –
Cam Plate and Ball Height 22.89 to 22.99 mm
0.9012 to 0.9051 in.
22.40 mm
0.8819 in.
Brake Disc Thickness 3.3 to 3.5 mm
0.130 to 0.137 in.
3.0 mm
0.118 in.
Friction Plate Thickness 1.92 to 2.08 mm
0.0756 to 0.0818 in.
1.52 mm
0.0598 in.
To Next Page
