STEERING
B2050, B2350, B2650, B3150, WSM
7-S3
2. SERVICING SPECIFICATIONS
POWER STEERING BODY
POWER STEERING CYLINDER
9Y1210982STS0002US0
Item Factory Specification Allowable Limit
Relief Valve Setting Pressure 11.5 to 12.5 MPa
118 to 127 kgf/cm
2
1670 to 1810 psi
–
Item Factory Specification Allowable Limit
Steering Cylinder I.D. 40.000 to 40.062 mm
1.57480 to 1.57724 in.
40.100 mm
1.57874 in.
Piston Rod to Guide Clearance 0.020 to 0.070 mm
0.00079 to 0.00276 in.
0.200 mm
0.00787 in.
To Next Page
