Operation
The following modules occupy an
address on the System, but have no
devices (and no device addresses).
 MKB  NET-7
 RCC-1/1F  NIM-1R
 CMI-300  RCM-1
Numeric Keypad
Use the numeric keypad (keys 0
through 9) when the System asks for a
module number, device number,
password, time, date, or other informa-
tion. The display shows each number
as you press the key (except when you
enter a password the System shows an
asterisk for each digit that you type).
Command Keypad
The command keys are described in
the following table:
device addresses. For events specific
to a module, the device is not required.
Fixed Addresses
A module may be assigned to any
address on the System, except for
some fixed addresses that have
already been assigned. (See the Fixed
Module Addresses Table.) The mod-
ules communicate to the MXL Control
Panel through a serial communications
network called MNET. The System
continuously supervises all of the
modules for presence and proper
operation.
You may assign a module to any
address on the System, and assign
addresses in any order, mixing differ-
ent types of modules and leaving gaps
in the numbering, provided you do not
use the fixed addresses.
COMMAND KEYPAD
Key Purpose
×
Select the item to the left of what is
flashing on the display (unless entering a
number).
Ø
Select the item to the right of what is
flashing on the display (unless entering a
number).
Ù
Go back to the previous item.
ENTER
Press to select the item on which the
cursor is flashing. After typing in numbers,
press ENTER to complete the entry.
HELP
Press to display a one-line message.
PRINT
Press to begin printing various lists and
reports.
FORM
FEED
Press to advance the paper in the printer.
CLEAR
Press to cancel printouts begun by
pressing PRINT. The System will print:
This listing prematurely terminated.
FIXED MODULE ADDRESSES
Module
Address
Module Device
Address
(Range)
0Do Not Use
1 Analog loop 1 (MMB-1/-2) 001-060
2 Analog loop 2 (MMB-1/-2) 001-060
3
ò
248 MKB-2
249 MKB-2
250 MKB-2
251 MKB-2, No.1
252 Reserved
253 MMB-1/-2 001 to 250
254 Programmer CSG-M
255 Global (reserved)
