Electrical ratings:

24 VDC, 17mA

5 VDC, 22mA

All wiring must be in accordance with

Article 760 of NEC or the local building

codes.

Maximum wire size:

14 AWG twisted pair, shielded

Minimum wire size:

18 AWG twisted pair, shielded

OCC-1 Connections and Ratings

4 - 59

Maximum loop resistance:

20 ohms for all wires

End of Line Resistors

Audio risers: 10K, ½W, 5%

P/N 140-820396

Telephone risers: 5.6K, ½W, 5%

P/N 140-820390
