1-20
Description
This MXLV was constructed to your
specifications based on your organ-
izations needs and may not include all
of the features possible on a fully
loaded MXLV System. Use the table of
contents to find the instructions
applicable to the features on your
system.
Overview of the Voice System
The MXLV is an emergency audio and
optional firefighters telephone pack-
age that is fully integrated into the
MXL System. In a multisystem net-
work, the MXLV supports selective
paging from a master command
console to remote voice systems. This
permits individual voice systems to be
connected to the local MXL while still
being controlled from the voice com-
mand console at the master MXL.
The MXLV supports up to three
channels of simultaneous audio. In any
channel configuration, the microphone
channel can be used to provide a tone
or message to any zone. Only one
tone, message, or announcement may
be routed to the same speaker zone at
one time. A priority sequence, called
PAGE, EVACUATE, ALERT, and
OTHER, controls which signal the zone
receives (See The Four Categories of
Sound, Chapter 3 - Operation for a
discussion of these priorities).
The Voice
System
(MXLV)
Capacity of the System
The system supports over 100 zones
which can be split between speaker,
telephone, and strobe zone addresses.
MXL, with remote transponder units,
supports the use of multiple command
consoles located in remote buildings.
The system can then be configured to
support all-call paging of remote build-
ings from a central location.
System Options
Firefighters Telephone System,
including a Master Telephone
used with firefighters telephones
Telephone-Busy Tone and
Dial Tone
Wardens Page that allows any
on-line telephone to act as a
paging microphone
Annunciator Modules
Transponder
Strobe Circuits
Remote Command Stations
