Siemens Cerberus PYROTRONICS MXL User Manual

3-37
Operation
each loop. XLD-1 modules have four
sequential module numbersone
number for each analog loop.
List: Voltages - Analog
The display for Analog voltage is
similar to the following (readings are
dynamic):
001-001 ANALOG2 = 2.75 VOLTS
List: Voltages - Thresh
The display for Threshold voltage is
similar to the following:
001-001 THRESHOLD = 4.75 VOLTS
List: Voltages - Sens
The display for Sensitivity voltage is
similar to the following (readings are
dynamic):
001-001 SENSTVTY = 2.00 VOLTS
NOTE: Only XLD-1 modules will have
the following additional List Voltage
menu items (These menu items will
not appear for ALD-2I modules):
List: Voltages - Calib
The display for XLD-1 calibration
voltage is similar to the following
(readings are dynamic):
003-001 CALIBRATION = 4.00 VOLTS
List: Voltages - ID
The display for XLD-1 ID voltage is
similar to the following (readings are
dynamic):
003-001 ID = 2.00 VOLTS
List: Voltages - ID2
The display for XLD-1 ID2 voltage is
similar to the following (readings are
dynamic):
003-001 ID2 = 0.00 VOLTS
If a binary data reading (in hexadeci-
mal) is wanted for any of the above
voltages, press the 0 key on the
numeric keypad to toggle the display
between the VOLTS response and the
HEX response. An example of the HEX
display is:
003-001 ANALOG2 = 16 HEX
NOTE: When you ask for any voltage,
the System displays Please wait for
response until it receives a reading
from the device; if you have just reset
the System, it alternates the above
message with the message Device
being initialized.
If the module number entered is not
an analog loop, the System displays:
Not Analog Loop
If the device address has no device
assigned by CSG-M, the System
displays:
No Device Assigned
When displaying sensitivities, if the
device is not a smoke detector, the
System displays:
Not a Smoke Detector
To print the voltages of all devices
assigned to a specified module,
press PRINT when the V in
Voltages is blinking. The System
