Electrical ratings:
Power requirement:
24 VDC, 3A at 30W
2A at 20W
1A at 10W
Battery drain:
160mA at supervision
3A max at 30W load
2A max at 20W load
1A max at 10W load
High Level Outputs:
25.2V RMS, 1.2A, 30W max
70.7V RMS, 0.42A, 30W max
Backup amplifier input:
1V RMS max
Frequency response:
300Hz5KHz ± 1dB
Fuse requirements:
0.8A, P/N 105-292965, for output
voltage 70.7V RMS
2.5A, P/N 105-291203, for output
voltage 25.2V RMS
ZAC-30 Connections and Ratings
4 - 115
Compatible Notification Appliances:
Refer to Compatible Notification
Appliances, P/N 315-096363.
Speaker/strobe appliances are compat-
ible for the speaker element only. For
the strobe element to work, the
appliance must also be wired to a ZC
series card, a CSM-4, or an ICP-B6.
Electrical connections:
All wiring must be in accordance with
Article 760 of NEC or the local building
codes.
Use unshielded twisted pair for high
level amplifier connections. Use
shielded twisted pair for terminals 1
and 2 of the backup amplifier. Connect
shield to terminal 2. Use single-con-
ductor wire for other connections.
