3-43
Operation
To leave the Dev_usage menu without
going through all subaddresses, press
the Up arrow
(Ù) key. The System
displays the List menu.
To print the device usages of de-
vices assigned to a specified mod-
ule, press PRINT when the D in
Dev_usages is blinking. The System
asks you for a module number:
Type In Module Number:
Type the three-digit module number
and press ENTER. The System prints a
list of all the devices assigned to that
module in a format similar to the
following:
Listing of Device Usages for Module 1 (ALD):
1- Alarm 3- Alarm
4- Alarm 5- Alarm
6- Alarm 8- Alarm
9- Alarm 10- Alarm
11- Alarm 12- Alarm
List: Node_address
Use List Node_address to display the
address of the panel which you are
currently using. The System displays in
a format similar to the following:
Node Address 3
If the panel is not part of a networked
System, it displays the following:
Not a Networked System
List: Percent/ft
Use List Percent/ft to show settings in
percent/ft obscuration of the ILI and
ILP series of detectors.
To display the percent/ft obscura-
tion of one device, press ENTER to
select Percent/ft. The System asks
you for a module number and device
number.
Type In Module & Device: -
Type the three-digit module number
and three-digit device number using
the numeric keypad and press ENTER.
The System shows the following menu
for that device (the S in Senstvty will
be blinking):
001-001 Senstvty Pre-alarm Analog
List: Percent/ft - Senstvty
The display for Sensitivity supplies the
current sensitivity as read back from the
detector and is similar to the following
(readings are dynamic):
002-003 Sens 1.4%/ft Norm
List: Percent/ft - Pre-alarm
The display for Pre-alarm supplies the
current pre-alarm setting read back
from the detector and is similar to the
following (readings are dynamic):
002-004 Pre-alarm 1.4%/ft Norm
List: Percent/ft - Analog
The display for Analog supplies the
current analog2 readings read from the
detector and is similar to the following
(readings are dynamic):
002-005 Sens 1.4%/ft Norm
