3-54
Operation
Enter the three-digit network address
of the ACM-1 module you wish to test
and press ENTER.
The System tests all the LEDs on the
VSM-1, VLM-1, and VFM-1 in sequence
red, green and yellow.
Test: X_Network
Use Test X_Network to display a series
of statistics typically used by Siemens
Building Technologies, Inc. to observe
network communications.
Test: M_Network
Use Test M_Network to display a
series of statistics typically used by
Siemens Building Technologies, Inc. to
observe network communications.
Test: NET7_Diags
Use Test NET7_Diags if a Loop A or
Loop B Trouble is posted, to display
which NET-7 module has reported the
trouble.
Select NET7_Diags and press ENTER.
The System displays the following
menu:
Current History
Select either Current or History to
display the NET-7 module(s) reporting
the trouble.
Test: Override
Use Test Override to override the
CSG-M selected options for Alarm
Verification and Alarm Confirmation.
Select Override and press ENTER. The
System displays the following submenu:
Alr Verify Alr Confirm
Test: Override - Alr_Verify
Select Alr_Verify and press ENTER. The
System shows the following submenu:
Override: Yes No
A blinking Y in Yes indicates that
Alarm Verification Override is currently
enabled. A blinking N in No indicates
that the Alarm Verification Override is
currently disabled.
To enable Alarm Verification
Override, use the right
(Ø) or left (×)
arrow keys to cause the Y in YES to
start blinking. Pressing ENTER when
the Y in YES is blinking will cause
Alarm Verification Override to be
enabled. The System will display the
following message:
Override Enabled
To disable Alarm Verification
Override, use the right (Ø) or left (×)
arrow keys to cause the N in NO to
start blinking. Pressing ENTER when
the N in NO is blinking will cause
Alarm Verification Override to be
disabled. The System will display the
following message:
Override Disabled
In either case, if the Alarm Verifi-
cation option was not selected in
CSG-M, the System will display
the following message:
Feature Not Enabled In CSG
