Operation
NOTE: If an alarm or supervisory is
reported from a device that is NOT in
Walktest, the Walktest is suspended
immediately. No further Walktest
events are annunciated or coded. The
Walktest remains running in the back-
ground of the MXL until it times out or
is canceled.
WARNING: When performing a partial
system Walktest, DO NOT TEST any
devices that are not in the Walktest,
as this will cause an alarm in the
System.
Walktest: Zone_wAUD / Zone_SIL
Use Walktest Zone_wAUD or Walktest
Zone_SIL to walktest an individual
conventional zone (CZM-1B6 or CZM-4).
Select Zone_wAUD (for audible
feedback) or Zone_SIL (for silence)
and press ENTER. The System asks
you for the module and device number
of the device you wish to test:
Type In Module & Device: -
Type the three-digit module number
and three-digit device number using the
numeric keypad and press ENTER.
If the address number entered is not
a CZM-1B6 or CZM-4 zone, the
System displays the following for 2
seconds:
Invalid type for Walktest
The display then returns to the
Walktest menu.
If the module type is an CZM-1B6 or
CZM-4 zone in the CSG-M, the PAR-
TIAL SYSTEM DISABLE LED lights,
the TROUBLE LED flashes, the internal
audible sounds, and the Walktest
activated trouble for the zone appears
on the trouble list. If a printer is in-
stalled, the trouble is also printed.
The LCD display reads:
In Walktest. Normal operation
disabled.
ENTER to continue.
Press ENTER or wait 60 seconds and
the display reads:
Walktest expires in 4 hrs
unless cancelled.
ENTER to continue.
Press ENTER, or wait 60 seconds and
the MXL returns to the Walktest menu.
(The MXL is in system Walktest.) The
LCD indicates the time remaining in
Walktest in the last five positions on the
display. The time is indicated in HH:MM
(hours:minutes) until less than one hour
remains, then it is indicated in MM:SS
(minutes: seconds).
Locate the device to be tested and
place that device in alarm (or trouble).
When the event is reported to the
MXL, the following sequence occurs:
When the System is in the audible
Walktest mode, all silenceable and
non-silenceable audibles that are not
already active or disarmed sound the
code, depending on how the device is
used in the CSG-M. (See the Walktest
Audible Codes table.)
WALKTEST AUDIBLE CODES
ALARM
2 seconds on, then off
SUPERVISORY
2 one-second pulses (on-off)
TROUBLE
4 seconds on, then off
SECURITY
4 one-second pulses (on-off)
STATUS
6 seconds on, then off
