Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.3 Contour turning
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
417
Parameter
Description
Unit
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇+∇∇∇ (complete machining)
Machining
direction
• Face
• Longitudinal
Position
• front
• back
• Inside
• outside
D Maximum depth infeed - (only for ∇) mm
XDA
1. Grooving limit tool (abs) – (only for face machining direction)
mm
XDB 2. Grooving limit tool (abs) – (only for face machining direction) mm
UX or U
Finishing allowance in X or finishing allowance in X and Z – (only for ∇)
mm
UZ
Finishing allowance in Z – (only for UX)
mm
DI
For zero: Continuous cut - (only for ∇)
mm
BL Blank description (only for ∇)
• Cylinder (described using XD, ZD)
• Allowance (XD and ZD on the finished part contour)
• Contour (additional CYCLE62 call with blank contour – e.g. cast iron mold)
XD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
• For blank description, cylinder
– Version, absolute:
Cylinder dimension ∅ (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
• For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
ZD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
• For blank description, cylinder
– Version, absolute:
Cylinder dimension (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
• For blank description, allowance
Allowance on the CYCLE62 finished part contour (inc)
mm
