IP COMMANDS
E-DOC-CTC-20100729-0006 v3.0.Copyright 2011Technicolor. All rights reserved.
This document contains Technicolor proprietary and confidential information. Passing on and copying of this document, use,
extraction and communication of its contents, is not permitted without written authorization from Technicolor.
563
ip arpadd
Add an entry to the ARP cache of a broadcast IP interface.
SYNTAX:
ip arpadd intf = <{lan1|wan1|dmz1|guest1}>
ip = <ip-range>
[hwaddr = <hardware-address>]
where:
intf The IP interface name. REQUIRED
ip The IP address [range] of the entry to add. REQUIRED
hwaddr The hardware address (e.g. Ethernet MAC address) of the
entry to add.
OPTIONAL
