Xerox 8850 Service Manual

03/2003
6-39
8850/ 510DP
General Tools and Supplies (NACO)
General Procedures
General Tools and Supplies (NACO)
Table 1 Supplies
Supplies
Description Part
Service Manual Binder 600P88124
Table 2 Tools
Tools
Description Part
Basic Multinational Tool Kit 600T1835
Supplemental Tool Kit 600T1837
Metric Supplemental Tool Kit 600T1836
Digital Multimeter 600T2020
DMM Test Lead Kit 600T1923
Test Leads (required for 600T2020) 600T1660
Red Adapter Plug 499T9567
Black Adapter Plug 499T9568
Electrometer 600T1620
Temperature Probe Set (Probe and Sensor) 499T9570
Thermal Sensor (straight) 499T9572
Light Shield 600T1198
Stackable Jumper Lead (Electrometer) 600T1652
Interlock Tool 600T91616
Vacuum Cleaner 600T1820
Vacuum Cleaner Bags (10) 93E3270
Vacuum Cleaner Filter Module 600T1832
Electrometer Probe Wing 600T1728
Screwdriver Blade (6” x 3/16”) 600T40203
Pocket Screwdriver 600T40205
5.5 mm Wrench 600T40501
7 mm Wrench 600T40502
5.5 mm Socket 600T40701
7 mm Socket 600T40702
Longnose Pliers 600T40901
Diagonal Cutting Pliers 600T40903
Metric Hex Key Set 600T41101
Retaining Ring Pliers 600T41401
150 mm Rule 600T41503
2 Meter Tape Measure 600T41505
Line Level 600T41510
Round File, 6 inch 600T41801
Flat File, 6 inch 600T41802
Cleaning Brush 600T41901
Scribing Tool 600T41903
Magnetic Pickup and Mirror 600T41911
Socket Driver 600T1751
Metric Feeler Gauge Set 600T41509
Screwdriver Handle 600T40212
13 mm Wrench 600T40505
10 mm Wrench 600T40504
Table 3 Image Reference Pattern
Image Reference Pattern
Solid Area Fill 82P520
Image Darkness 82E7030
Background 82P502
Table 4 Machine Consumable
Machine Consumable
Description Part
Photoreceptor 1R535
Toner Cartridge (with Reclaim Bottle) 6R989
Developer (7 lb. bottle) 5R633
Dusting Pouch 8R181
Table 5 Cleaning Materials
Cleaning Materials
Description Part
Cleaning Solvent 43P10
Disposable Gloves 99P3024
Drop Cloth 35P1638
Film Remover 43P45
Formula A 43P48
Heavy Duty Towels 35P3191
Lint-free Cloth 600S4372
Polyurethane Pads (40) 600S4653
Photoreceptor Maintenance Kit 600S5838
Table 6 Other Tools and Supplies
Other Tools and Supplies
Description Part
20 lb. Roll Bond Media 22E630
Oil Tube (8 cc) 93E811
Log Holder 600P293
Media Message 600P60017
