ABB IRC5 User Manual

2 Installation and Commissioning, IRC5
2.9.8. Upgrading and installation of 2X Euromap interface (Option 671-4)
1333HAC021313-001 Revision: K
© Copyright 2004-2008 ABB. All rights reserved.
Required equipment for 2X Euromap interfaces in the Single Cabinet Controller
Required equipment for 2X Euromap interfaces in the Dual Cabinet
Installation of interfaces in the Single Cabinet Controller
Equipment Art. number Description Note
Cable harness 3HAC026692-001 Harness-Euromap 67
DCC
Single Cab.
Gasket 3HAC024175-001
Harness-Euromap 67
adapter
3HAC032370-001
Terminal block 3HAC17833-1
Marking card 3HAC17833-6
Standard tools
Equipment Art. number Description Note
Cable harness 3HAC026821-001 Harness-Euromap 67
DCC
Dual Cab.
Gasket 3HAC024175-001
Harness-Euromap 67
adapter
3HAC032370-001
Terminal block 3HAC17833-1
Marking card 3HAC17833-6
Standard tools
Action Note/Illustration
1.
DANGER!
Before any work inside the
cabinet, please observe the
safety information in section
DANGER - Make sure that
the main power has been
switched off! on page 28.
2.
esd
WARNING!
The unit is sensitive to ESD,
before handling the unit
please observe the safety
information in section
WARNING - The unit is
sensitive to ESD! on page 29
Continued
Continues on next page
