2.5.8. Fitting the connector
General
This section details how to fabricate a cable for connecting the mains power to the Drive
Module.
Specifications
The following details the cable and fuse requirements for the mains power connection to the
Drive Module.
Included parts
The following parts are included in the delivery.
Procedure
The following details how to fit the connectors
Component Description
Cable typ Flexible oil resistant rubber
Cable area 4 x 6mm2
Fuse Delay action fuse 25A
Part Qty
Female contact 1
Contact housing 1
Brass cable clamp with gasket 1
Action Note/Illustration
1. Select a suitable three phase + earth cable and cut
it to desired lenght.
See specifications above.
2. Make sure all parts required are available. Specified in Included parts above.
