2 Installation and Commissioning, IRC5
2.5.15. Connecting a Limit switch override push button
3HAC021313-001 Revision: K82
© Copyright 2004-2008 ABB. All rights reserved.
2.5.15. Connecting a Limit switch override push button
DANGER!
The Limit switch override is used to disconnect safety limitations. Make sure the Limit switch
override function is not active longer than absolutely necessary.
If the option SafeMove is implemented, Limit switch override must never be used at all. The
SafeMove safety controller has its own override function.
General
The override circuit enables the possibility to jog an axis out of a forbidden (limited) zone.
Limitations
The switch has to be placed inside the controller to eliminate the risk of electrical noise.
Required equipment
Procedure for Single Cabinet Controller
The following procedure details how to connect a Limit switch override circuit in a Single
Cabinet Controller.
Equipment Art. no Note
Contact block 1SFA 610 605 R1001 ABB CW Control
Contact blocks with holder 1SFA 611 605 R1201 ABB CW Control
Push button (in Dual Cabinet) 1SFA 611 102 R1105 ABB CW Control
Connector X23 1SSA 245 204 R0100 ABB CW Control
Wire Cable AWG 20 Blue
Standard toolkit Described in section,
Standard Toolkit.
Circuit diagram See Circuit Diagram on
page 341
Action Note/illustration
1.
Danger
DANGER!
Before any work inside the IRC5 controller
modules, please observe the safety
information in section DANGER - Make
sure that the main power has been
switched off! on page 28.
Continues on next page
