We reserve all rights in this document and in the information contained therein.Reproduction, use or
disclosure to third parties without express authority is strictly forbidden. © Copyright 2003 ABB
Latest revision:
Prepared by, date: Approved by, date:
EUROMAP 67
EUROMAP 12/SPI
Lab/Office:
REVISION INFORMATION
Graphics
Status:
Document no.
3HAC024120-004
Plant:
Location:
Sublocation:
Rev. Ind
=
+
+
EUROMAP
CM.1
03
Page
Next
Total
3
5
48
Approved
2008-07-17
Revison information 02
Sh.13 Connection changed at XT31
Sh 24-29 Changed new computer.
Sh.39 Added connections.
Sh.40 Added connections.
Sh.49 Added contact I/O1.X1 and I/O1.X2
Sh.50 Added contact I/O.X3
Revison information 03
Sh 14.1 added for e stop with 2 IMM.
Sh 51 and 52 added for 2 IMM
Sh 49 connection om I/O1.X1 changed and I/O1.X2 deleted.
Sh 40 Connections changed.
