ABB IRC5 User Manual

We reserve all rights in this document and in the information contained therein.Reproduction, use or
disclosure to third parties without express authority is strictly forbidden. © Copyright 2003 ABB
Latest revision:
Prepared by, date: Approved by, date:
Lab/Office:
CONTROL SYS. IRC5 M2004 DESIGN 06
Device: =CAB+CM-1 - =CAB.DC+CM-G5
Device list
Status:
Document no.
3HAC024480-004
Plant:
Location:
Sublocation:
Rev. Ind
=
+
+
CAB
CM
03
Page
Next
Total
10
11
153
Approved
2008-07-17
Location name Location description Page Location name Location description Page
=CAB+CM- -1 52
=CAB+CM-A61 -1 73
=CAB+CM- -2 52
=CAB+CM- -10084 73
=CAB+CM- -10085 73
=CAB+CM- -10086 73
=CAB+CM- -A3 COMPUTER UNIT AC/BD 53
=CAB+CM- -A21 PANEL BOARD 38
=CAB+CM- -A21 PANEL BOARD 42
=CAB+CM- -A21 PANEL BOARD 43
=CAB+EXT- -A21 EXT.CONTROL PANEL 43
=CAB+CM- -A21 PANEL BOARD 44
=CAB+EXT- -A21 EXT.CONTROL PANEL 44
=CAB+CM- -A21 PANEL BOARD 45
=CAB+EXT- -A21 EXT.CONTROL PANEL 45
=CAB+CM- -A21 PANEL BOARD 46
=CAB+EXT- -A21 EXT.CONTROL PANEL 46
=CAB+CM- -A21 PANEL BOARD 49
=CAB+EXT-A21 -A22 ADAPTER 43
=CAB+EXT-A21 -A22 ADAPTER 44
=CAB+EXT-A21 -A22 ADAPTER 45
=CAB+EXT-A21 -A22 ADAPTER 46
=CAB+CM- -A23 OPTION:STATUSLED ON FRONT 39
=CAB+CM- -A31 MAIN COMPUTER DSQC639 50
=CAB+CM- -A32 ROBOT COMMUNICATION CARD 56
=CAB+CM- -A33 PROFIBUS DP M/S 57
=CAB+CM- -A33.1 PROFINET DSQC678 57.1
=CAB+CM- -A34 DUAL RS232 CARD 61
=CAB+CM- -A35 DEVICE NET ADAPTER 59
=CAB+CM- -A36 ETHERNET CARD 62
=CAB+CM- -A37 INTERBUS M/S (OPTICAL FIBRE) 58
=CAB+CM- -A37 INTERBUS M/S (COPPER WIRE) 58
=CAB+CM- -A38.1 ETHERNET/IP Fieldbus adapter DSQC 669 52
=CAB+CM- -A38.2 PROFIBUS Fieldbus adapter DSQC 667 52
=CAB+CM- -A38.3 PROFINET Fieldbus adapter DSQC 688 52
=CAB+CM- -A39 OPTION:232/422/485 SERIE CONVERTER 51
=CAB+CM-A3 -A39 OPTION:232/422/485 SERIE CONVERTER 55
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 90
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 111
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 121
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 131
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 141
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 151
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 161
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 171
=CAB+DM- -A41.1 MAIN SERVO DRIVE UNIT 201
=CAB+DM- -A41.1.3 SINGLE SERVO DRIVE UNIT 95
=CAB+DM- -A41.1.3 SINGLE SERVO DRIVE UNIT 98
=CAB+DM- -A41.1.4 SINGLE SERVO DRIVE UNIT 96
=CAB+DM- -A41.1.4 SINGLE SERVO DRIVE UNIT 99
=CAB+DM- -A41.1.5 SINGLE SERVO DRIVE UNIT 97
=CAB+DM- -A41.1.5 SINGLE SERVO DRIVE UNIT 99
=CAB+DM- -A41.2 RECTIFIER 93
=CAB+DM- -A41.3 CAPACITOR UNIT 93
=CAB+DM- -A42 AXIS COMPUTER BOARD 90
=CAB+DM- -A43 CONTACTOR UNIT 88
=CAB+DM- -A44 OPTION : EPS 92
=CAB+DM- -A44 OPTION: SAFE MOVE DSQC647 92.1
=CAB+CM- -A61 OPTION: REMOTE SERVICE BOX 73
=CAB+DM- -C1 CAPACITOR 172
=CAB+CM-A3 -D32 SOLID STATE DRIVE 53
=CAB+DM- -F1 AUTOMATIC FUSE 89
=CAB.DC+DM- -F2 AUTOMATIC FUSE 85
=CAB.SC+DM- -F2 AUTOMATIC FUSE 86
=CAB.SC+DM- -F2 AUTOMATIC FUSE 87
=CAB+DM- -F4 EARTH FAULT BREAKER 84
=CAB+DM- -F5 CIRCUIT BREAKER 84
=CAB+DM- -F6 OPTION:CIRCUIT BRAKER 82
=CAB+CM- -FPU1 FLEXPENDANT 47
=CAB+CM- -FPU1 FLEXPENDANT 48
=CAB.DC+DM- -G1 DRIVE POWER SUPPLY 85
=CAB.SC+DM- -G1 DRIVE POWER SUPPLY 86
=CAB.SC+DM- -G1 POWER SUPPLY 87
=CAB+CM- -G2 PROCESS POWER SUPPLY 33
=CAB.SC+DM- -G2 POWER DISTRIBUTION BOARD 87
=CAB+CM- -G3 ULTRA CAP 33
=CAB.SC+DM- -G3 ENERGY BANK 87
=CAB.DC+CM- -G4 CUSTOMER POWER SUPPLY 34
=CAB.DC+CM- -G4 CUSTOMER POWER SUPPLY 35
=CAB.SC+CM- -G4 CUSTOMERPOWERSUPPLY 36
=CAB.DC+CM- -G5 CUSTOMER POWER SUPPLY 34
=CAB.DC+CM- -G5 CUSTOMER POWER SUPPLY 35
