2 Installation and Commissioning, IRC5

2.9.9. Installation of cooling fan harness axis 1 and 2

1393HAC021313-001 Revision: K

2.9.9. Installation of cooling fan harness axis 1 and 2

General

If the robot is going to be supplemented with cooling fans on axis 1 and 2 the controller has

to be supplemented with a internal harness.

Locations in Dual Cabinet Controller

xx0600002685

A Harness, cooling - Axis 1 and 2

B Cover with cable gland

C Contactor interface board

D Connector A43.X10

E Connector A43.X11

Continues on next page
