13-26
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 13 Configuring CEF for PFC2 and PFC3A
Configuring CEF for PFC2/PFC3A on the Switch
Clearing the IP Multicast Statistics
The clear mls multicast statistics command clears the IP multicast statistics.
To clear the IP multicast statistics, perform this task in privileged mode:
This example shows how to clear the IP multicast statistics:
Console> (enable) clear mls multicast statistics
All statistics for the MLS routers in include list are cleared.
Console> (enable)
Displaying the IP Multicast Entries
The show mls multicast entry command displays a variety of information about the multicast flows that
are being handled by PFC2/PFC3A. You can display entries that are based on any combination of the
participating MSFC2/MSFC3, the VLAN, the multicast group address, or the multicast traffic source.
To display information about the IP multicast entries, perform this task in privileged mode:
This example shows how to display all the IP multicast entries:
Console> (enable) show mls multicast entry all
Router IP Dest IP Source IP Pkts Bytes InVlan OutVlans
--------------- --------------- --------------- ---------- ----------- ------- --------
1.1.5.252 224.1.1.1 1.1.11.1 15870 2761380 20
1.1.9.254 224.1.1.1 1.1.12.3 473220 82340280 12
1.1.5.252 224.1.1.1 1.1.12.3 15759 2742066 20
1.1.9.254 224.1.1.1 1.1.11.1 473670 82418580 11
1.1.5.252 224.1.1.1 1.1.11.3 15810 2750940 20
1.1.9.254 224.1.1.1 1.1.12.1 473220 82340280 12
1.1.5.252 224.1.1.1 1.1.13.1 15840 2756160 20
1.1.9.254 224.1.1.1 1.1.13.1 472770 82261980 13
1.1.5.252 224.1.1.1 1.1.12.1 15840 2756160 20
1.1.9.254 224.1.1.1 1.1.11.3 473667 82418058 11
Total Entries: 10
Console> (enable)
Task Command
Clear the IP multicast statistics. clear mls multicast statistics
Task Command
Display information about the IP multicast
entries.
show mls multicast entry [[[mod] [vlan vlan_id]
[group ip_addr] [source ip_addr]] | [all]]
