13-27
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 13 Configuring CEF for PFC2 and PFC3A
Configuring the NetFlow Statistics on the Switch
This example shows how to display the IP multicast entries for a specific MSFC2/MSFC3:
Console> (enable) show mls multicast entry 15
Router IP Dest IP Source IP Pkts Bytes InVlan OutVlans
--------------- --------------- --------------- ---------- ----------- ------- --------
1.1.5.252 224.1.1.1 1.1.11.1 15870 2761380 20
1.1.5.252 224.1.1.1 1.1.12.3 15759 2742066 20
1.1.5.252 224.1.1.1 1.1.11.3 15810 2750940 20
1.1.5.252 224.1.1.1 1.1.13.1 15840 2756160 20
1.1.5.252 224.1.1.1 1.1.12.1 15840 2756160 20
Total Entries: 5
Console> (enable)
This example shows how to display the IP multicast entries for a specific multicast group address:
Console> (enable) show mls multicast entry group 226.0.1.3 short
Router IP Dest IP Source IP InVlan Pkts Bytes OutVlans
-------------- ----------- ------------ ------ ------ --------- ---------
171.69.2.1 226.0.1.3 172.2.3.8 20 171 23512 10,201,22,45
171.69.2.1 226.0.1.3 172.3.4.9 12 25 3120 8,20
Total Entries: 2
Console> (enable)
This example shows how to display the IP multicast entries for a specific MSFC2/MSFC3 and a specific
multicast source address:
Console> (enable) show mls multicast entry 15 source 1.1.11.1 short
Router IP Dest IP Source IP Pkts Bytes
InVlan OutVlans
--------------- --------------- --------------- ---------- --------------------
------ ----------
172.20.49.159 224.1.1.6 1.1.40.4 368 57776
40 23,25
172.20.49.159 224.1.1.71 1.1.22.2 99 65142
22 30,37
172.20.49.159 224.1.1.8 1.1.22.2 396 235620
22 13,19
Console> (enable)
Configuring the NetFlow Statistics on the Switch
Note With Supervisor Engine 720 (MSFC3), IPX routing is done through the software.
These sections describe how to configure the NetFlow statistics:
• Specifying NetFlow Table Entry Creation on a Per-Interface Basis, page 13-28
• Specifying the NetFlow Table Entry Aging-Time Value, page 13-29
• Specifying the NetFlow Table IP Entry Fast Aging Time and Packet Threshold Values, page 13-30
• Setting the Minimum Statistics Flow Mask, page 13-31
• Excluding the IP Protocol Entries from the NetFlow Table, page 13-31
• Displaying the NetFlow Statistics, page 13-31
• Clearing the NetFlow IP and IPX Statistics, page 13-34
• Displaying the NetFlow Statistics Debug Information, page 13-36
