Chapter 30 Configuring DNS

Configuring DNS on the Switch

Disabling DNS

To disable DNS, perform this task in privileged mode:

This example shows how to disable DNS on the switch:

Console> (enable) set ip dns disable

DNS is disabled

Console> (enable)

Task Command

Step 1

Disable DNS on the switch. set ip dns disable

Step 2

Verify the DNS configuration. show ip dns [noalias]
