English–DPI620G Instruction Manual | 1
Introduction
1. Overview
1.1 Introduction
The Druck DPI620G is a battery powered instrument for electrical measurements, a source of
currents and voltages, and for HART® communications. Two more optional data protocols can
be
installed in the instrument: FOUNDATION™ Fieldbus and the Profibus® PA. The DPI620G
supplies the power and user interface options for all available functions. The display is a
touchscreen that can have a maximum of six channel screens in which to show different
parameters.
There are three types of the DPI620G instrument: DPI620G, DPI620G-B and the DPI620G-IS.
The
DPI620G is for general use. The DPI620G-IS (Intrinsically Safe) type is for use in areas that
possibly have explosive gases. The DPI620G-B has only one electrical channel and has to attach
to another device, for example, a PV62X or PV624 pressure station, to function as a pressure
calibrator.
You use the CALIBRATOR function in the DPI620G user interface to calibrate and test pressure
se
nsors and to test different types of switch.
The use of a type of MC620G module carrier or PV62X/PV624 pressure station, adds functions
to
the DPI620G. For information about these pressure stations, refer to manuals (132M9253) for
the PV62X and (174M7583) for the PV624.
The DPI620G and DPI620G-B are compatible with the PV624 pressure station but the
DP
I620G-IS is not.
The Druck DPI620G can have Bluetooth hardware as an option, for use with the PV624 device.
Re
fer to the PV624 documentation for information about how to use the DPI620G user interface
with this data protocol.
This version of the manual is applicable to software revisions DK420 V05.00.00 and above.
1.2 What is supplied
These items are supplied with the instrument:
Table 1-1
: DPI620G Types
DPI620G DPI620G-B DPI620G-IS
Druck DPI620G multifunction
calibrator
Druck DPI620G-B multifunction
ca
librator
Druck DPI620G multifunction
calibrator _ Intrinsically Safe
Li-polymer battery Li-polymer battery Li-Ion battery pack
Mains Adapter Mains Adapter
Mains Adapter for battery
c
h
arger
Battery Charger Body
AC Probe
Set of six test leads Set of four test leads Set of six test leads
Stylus Stylus Stylus
Quick Start & Safety Manual Quick Start & Safety Manual Quick Start & Safety Manual
