English–DPI620G Instruction Manual | 163
Profibus® Application – Connecting to a Network
2. Tap on the PROFIBUS® channel to make it change to its expanded form.
Figure 11-5: Calibrator Profibus® Channel
3. Tap the Settings icon to configure the network.
4. Tap the Back icon to go back to the PROFIBUS® channel view.
11.5 Profibus® Application – Connecting to a Network
Tap the Profibus® icon on the expanded Profibus® channel to start the application.
Figure 11-6: Profibus® Application
If the application does not open and an error message appears, make sure that the unit is a
DP
I620G-PB or DPI620G-FFPB.
Note: Updating CH1, P1, and P2 tasks is only possible when the PROFIBUS® application is not
in operation.
Note: Make sure the DPI620G USB setting is in the Storage Device mode. See Section 2.4.4 on
page 28.
